LD-FR-SJS-DC24V-XXXX-144-10*10mm Neon Flex (Hollow extrusion)

  1. 10*10mm neon flex is a member of whole silicone neon series with slim and soft light body.
  2. The lighting effect stays continous without any dark dots.
  3. Unique design in structure of 3sides wide lighting effect.
  4. Cut freely and joint freely.
  5. Pure silicone extrusion and automated production.
  6. flexible and bendable.
  7. Reliable quality with 5 years warranty.
  8. UV & flame resistant.
  9. Application for outdoor or indoor boarder lighting,architectural outline,cove, facade,signage or guide lighting.

Type Neon
Color Red, Blue, Green, White
Working voltage DC24V
Rated Power/mtr 12W, 14W
LED Qty/mtr 144LEDs
CCT 2700K, 3000K, 3500K, 4000K, 5000K, 6000K
LM/m 1000Lm
LED Distance 0.69cm
PCB Size 10mm, 8mm
Min cutting unit 1LEDs (1unit)
Min cutting length 0.69cm(1unit)
Conttnous length 10m
weight/m 210g
Storing Temp. -40~60℃
Working Temp -40~45℃
IR Rating IP67
