Features
Product Features
- Efficacy: CRI90+ up to 120lm/w.
- Uniform light(Dot-free).
- Super narrow.
- Waterproof option: IP20, IP65, IP67, IP68
- Suitable for office, residential, retail and decorative lighting.
- CRI80+,90+,95+optional.
- Warranty:3 years.
Dimensions
20(1) 20(2)
21(1) 21(2)
22(2) 23(2)
24(1) 24(2)
25(2) 26(1)
For more dimensions information, please feel free to contact us.
Applications
Packaging
Certifications
| Item No. | Size | Cutting Unit | Input Voltage | Input Current | Typ-power | Max. Power | Bend Diameter | Copper foil | CRI | CCT | LM/m | LM/W | Efficiency Class |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LD-FOBXX320K1103N1-24 | 5000×8×1.5mm | 16LEDs/50mm | DC24V | 0.42A/m | 10.0W/m | 11.0W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 900/950/1000/1000/950 | 90/95/100/100/95 | F |
| LD-F0BXX378K723N1-24 | 5000×8×1.5mm | 21LEDs/55.55mm | DC24V | 0.42A/m | 10.0W/m | 11.0W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 900/950/1000/1000/950 | 90/95/100/100/95 | F |
| LD-F0BXX480K952N1-24 | 5000×8×1.5mm | 24LEDs/50mm | DC24V | 0.42A/m | 10.0W/m | 11.0W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 950/1000/1050/1050/100 | 95/100/105/105/100 | F |
| LD-F0B320-9XX-24 | 5000×8×1.5mm | 32LEDs/62.5mm | DC24V | 0.42A/m | 10.0W/m | 11.0W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 950/1000/1050/1050/100 | 95/100/105/105/100 | F |
| LD-F0B320-9XX-24 | 5000×10×1.5mm | 16LEDs/50mm | DC12V | 0.84A/m | 10W/m | 11W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 900/950/1000/1000/950 | 90/95/100/100/95 | F |
| LD-F0BXX360K785N1-12 | 5000×8×1.5mm | 9LEDs/25mm | DC12V | 0.84A/m | 10.0W/m | 11.0W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 720/760/800/800/760 | 72/76/80/80/76 | F |
| LD-FOBXX480K805N1-24 | 5000×4×1.5mm | 24LEDs/50mm | DC24V | 0.125A/m | 3.0W/m | 3.3W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 270/285/300/300/285 | 90/95/100/100/95 | F |
| LD-FOBXX480K806N1-24 | 5000×6×1.5mm | 24LEDs/50mm | DC24V | 0.21A/m | 5.0W/m | 5.5W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 450/475/500/500/475 | 90/95/100/100/95 | F |
| LD-FOBRGB840K835N1-24 | 5000×10×1.5mm | 42LEDs/50mm | DC24V | 0.6A/m | 14.4W/m | 15.84W | >60mm | 2oz | – | RGB | – | – | – |
| LD-FOBCCT840K836N1-24 | 5000×10×2.5mm | 42LEDs/50mm | DC24V | 0.42A/m | 10.0W/m | 11.0W | >60mm | 2oz | >90 | 2700K/6500K/2700K+6500K | 310/475/780 | 62/95/78 | – |
| LD-FOBXX320K764N1-24 | 5000×8×1.5mm | Uncuttable | DC24V | 0.42A/m | 10.0W/m | 11.0W | >60mm | 2oz | >90 | 2700K/6500K/2700K+6500K | 810/855/900/900/873 | 81/86/90/90/87 | F |
| LD-FOB240-9XX-24 | 5000×8×1.6mm | Uncuttable | DC24V | 0.42A/m | 10W/m | 11W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 855/903/950/950/922 | 86/90/95/95/92 | F |
| LD-FOB896-RGBW-24 | 5000×12×1.5mm | 56LEDs/62.5mm | DC24V | 0.5A/m | 16W/m | 17.6W | >60mm | 2oz | >90 | RGBW | – | – | – |
| LD-FOBRGB840K835N1-24 | 5000×10×1.5mm | 42LEDs/50mm | DC24V | 0.6A/m | 15W/m | 16.5W | >60mm | 2oz | – | RGB | – | – | – |
| LD-FOB528-9XX-24 | 5000×10×1.5mm | 24LEDs/45.45mm | DC24V | 0.6A/m | 15W/m | 16.5W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 1254/1330/1390/1385/1335 | 90/95/99/99/95 | F |
| LD-FOB640-2765-24 | 5000×10×1.5mm | 32LEDs/50mm | DC24V | 0.65A/m | 16W/m | 17.6W | >60mm | 2oz | >90 | 2700K/6500K/270K+6500K | 572/572/1108 | 72/72/70 | – |
| LD-FOBXX320K951N1-24 | 5000×8×1.5mm | 32LEDs/100mm | DC24V | 0.34A/m | 8W/m | 8.8W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 890/920/966/942/910 | 111/115/121/118/114 | F |
| LD-FOB384-9XX-24 | 5000×10×1.5mm | 16LEDs/41.67mm | DC24V | 0.5A/m | 12W/m | 13.2W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 1396/1370/1440/1425/1382 | 116/114/120/119/115 | F |
| LD-FOB840-RGBCCT-24 | 5000×12×1.5mm | 35LEDs/41.6mm | DC24V | 0.6A/m | 16W/m | 17.6W | >60mm | 2oz | >90 | RGBCCT | – | – | – |
| LD-FOB504-9XX-24 | 5000×12×1.5mm | 42LEDs/83.33mm | DC48V | 0.2A/m | 10W/m | 11W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 833/879/925/903/885 | 83/88/93/90/89 | G |
| LD-FOB504-9XX-24 | 5000×12×1.5mm | 28LEDs/55.55mm | DC48V | 0.2A/m | 10W/m | 11W | >60mm | 2oz | >90 | 2700K/3000K/4000K/5000K/6000K | 1045/1102/1160/1135/1113 | 105/110/116/114/111 | F |
